Audi A4 Wheel Offset Chart

We are going to give you some tips on Audi A4 wheel offset you should know before you pick up a set of wheels for your vehicle.

A good wheel in the right setup is going to make the difference between something that just was not thought out and pretty much guessed.

If you are trying to figure out what your set of wheels for Audi A4 should be and after visiting tons of forums still left with more questions than answers, than this is your final stop. Lots of people do not understand the principles of diameter, width and offsets.

Audi A4 Wheel Offset

2023 2022 2021
Shop for Tires at Tire Rack.

A4 Bolt Pattern	PCD 5x112 See Adapters
Center bore (hub bore)	66.5 mm Use Hub Centric Rings
Thread Diameter	M14 x 1.5 Lug Nuts
Stock Rim Sizes Range	x – x Hubcaps

Audi A4 Wheel Offset

2020 2019 2018 2017 2016 2015 2014 2013 2012 2011 2010 2009
Shop for Tires at Tire Rack.

Stock wheel offset	28 to 47 mm Try Wheel Spacers
A4 Bolt Pattern	PCD 5x112 See Adapters
Custom Offset Range	-5 to 55 mm
Center bore (hub bore)	66.6 mm Use Hub Centric Rings
Thread Diameter	M14 x 1.5 Lug Nuts
Stock Rim Sizes Range	17x7.0 – 20x9.0 Hubcaps
Custom rim sizes range	17x10.0 – 22x9.5 Custom Wheels

2020-2009 Audi A4 Custom Wheel Offsets

Rim size	Offset
19x9.5	22-45
19x8.5	25-48
20x9.0	25-48
20x10.0	25-44
19x10.0	25-55
19x9.0	28-52
19x8.5 / 19x10.0	17-38
18x8.5	29-45
20x8.5	33-38
20x10.5	23-30

Audi A4 Wheel Offset

2008 2007 2006 2005 2004 2003 2002 2001 2000 1999
Shop for Tires at Tire Rack.

Stock wheel offset	32 to 45 mm Try Wheel Spacers
A4 Bolt Pattern	PCD 5x112 See Adapters
Custom Offset Range	12 to 59 mm
Center bore (hub bore)	57.1 mm Use Hub Centric Rings
Thread Diameter	M14 x 1.5 Lug Nuts
Stock Rim Sizes Range	15x6.0 – 20x9.0 Hubcaps
Custom rim sizes range	17x10.0 – 20x9.5 Custom Wheels

2008-1999 Audi A4 Custom Wheel Offsets

Rim size	Offset
19x8.5	32-59
18x8.5	26-38
18x8.0	28-45
18x8.5 / 18x9.5	12-45
19x8.5 / 19x9.5	28-38
19x8.0	25-35
20x9.0	32-35
17x8.0	32-48
19x9.0	24-38
18x8.5 / 18x10.0	13-37
